NAD PP2e Phono Preamplifier

MC:
Input Impedance (R and C): 100 Ohm + 180pF
Gain at 1kHz: 60dB
Input Sensitivity (ref. 200mV output): 0.3mV
Signal to Noise Ratio: 78dB (A weighted, with cartridge connected)
Input Overload (20Hz/1kHz/20kHz): 0.8/9/84mV
Rated Distortion (THD 20Hz - 20kHz): <0.03%
RIAA Response Accuracy: ±0.3dB

MM:
Input Impedance (R and C): 47 kilohm + 200pF
Gain at 1kHz: 35dB
Input Sensitivity (ref. 200mV output): 2.5mV
Signal to Noise Ratio: 80dB (A weighted, with cartridge connected)
Input Overload (20Hz/1kHz/20kHz): 10/102/950mV
Rated Distortion (THD 20Hz - 20kHz): <0.03%
RIAA Response Accuracy: ±0.3dB

LINE OUT:
Output Impedance: 100 Ohm
Maximum Output Level: 5.3V

GENERAL:
AC Supply: External 23.5V DC
Dimensions excl. Power supply (W x H x D):
135 x 49 x 72mm
5 5/16 x 1 15/16 x 2 7/8"
